Get Started

Components

  1. Cypherock SDK HW Connect:

    • Packages name format: @cypherock/sdk-hw-*
    • These packages will allow you to connect to the Cypherock X1 Hardware Wallet with different technologies, like: WebUSB, HID

  2. Cypherock SDK Applications:

    • Packages name format: @cypherock/sdk-app-*
    • The packages through which you will be able to invoke operations on the Cypherock X1 Hardware Wallet

1. Select HW Connect Technology

This layer allows you to connect with the Cypherock X1 hardware wallet with different technologies: WebUSB and HID.

You can use the below table to select between WebUSB and HID.

Technology Supported Platform Package
WebUSB Web Apps @cypherock/sdk-hw-webusb
HID Desktop Apps with NodeJS/ElectronJS @cypherock/sdk-hw-hid

2. Create Connection

All HW Connect packages export a create function which can be used to create a connection instance of the connected Cypherock X1 hardware wallet.

Install package: npm i @cypherock/sdk-hw-hid

Example:

// Import device connection
// NOTE: You can use @cypherock/sdk-hw-webusb for WebUSB
import { DeviceConnection } from "@cypherock/sdk-hw-hid";

// Creates a device connection. Throws error if no device connetion is found
const connection = await DeviceConnection.create();

There are more methods in DeviceConnection which can be found in the documentation of the respective packages. For the sake of this example, we will only use the create method.

3. Select a Wallet

Since Cypherock X1 Vault supports multiple wallets, you will need to select the wallet you want to use.

Using @cypherock/sdk-app-manager we fetch a list of all the wallets available on the device.

Install package: npm i @cypherock/sdk-app-manager

import { ManagerApp } from "@cypherock/sdk-app-manager";

// Create manager app instance
const managerApp = await ManagerApp.create(connection);

// Get all wallets available on device
const allWallets = await managerApp.getWallets();

// Ask the user to select a wallet they want to use
const selectedWallet = await askUserToSelectAWallet(allWallets);

4. Execute Operation

For this example we will assume we want to get a list a ETH addresses from the device. We will use the EVM App to do that.

Install package: npm i @cypherock/sdk-app-evm

import { EvmApp } from "@cypherock/sdk-app-evm";

// Create evm app instance
const evmApp = await EVMApp.create(connection);

const { addresses } = evmApp.getPublicKeys({
        walletId: selectedWallet.id,
        derivationPaths: [
          {
            // m/44'/60'/0'/0/0
            path: [0x80000000 + 44, 0x80000000 + 60, 0x80000000, 0, 0],
          },
        ],
        chainId: 1,
    });

5. Destroy the connection

Once the device connection is no longer needed you should destroy it.

await connection.destroy();

NOTE

  • Do not destroy the connection if you'll need to connect to the same device again.
  • Destroying the application will also destroy the connection.
// This will destroy the device connection as well
await evmApp.destroy();
